Performance features:
The machine is equipped with dual motors and an imported narrow v-belt driving system, which renders an excellent transmission ratio, powerful driving forces and sound transmission. It will not bring pollution resulted from oil leakage and little noise will be generated; the compressor is convenient in operation and maintenance;
The maximized design of roller will effectively improve its production capacity and ensures a rapid and convenient clearance adjustment;
The lubricant refueling unit equipped in the main engine is capable of refueling without stopping the engine;
A special shear pin device is installed to prevent the main shaft from been stuck by impurities which will lead to equipment damage; the safety pin is easy to be dismantled and assembled;
The assembly of steel circular moulds made from high chrome alloy consists of screw type and anchor-ear type and their dismantling and assembling methods are both quick and convenient. To maximize the profits, users, while placing orders for goods, can choose the circular moulds with different aperture and thickness in accordance with their needs;
In light of different users and various traits of feed, you can choose the optimal linear velocity of circular moulds;
The part of compressor that is in contact with material is made of stainless steel;
Apart from the standard configuration, the stainless quality conditioner offers extended uniaxial, biaxial differential and quality-assurance unit according to users’ demand
The compressor adopts the advanced variable frequency motors in material feeding, and it is installed with a overload protection device and external discharging device;
It applies to the pellet compressing of high quality livestock material, aquatic feed, compound fertilizer and biomass.
Major Technicai Parameters
| Product model | TLZL-25 | TLZL-32 | TLZL-35 | TLZL-40 | TLZL-42 | TLZL-52 |
|---|---|---|---|---|---|---|
| Main engine power (KW) | 22 | 22*2 | 30*2 | 45*2 | 55*2 | 75*2 |
| production capacity (t/h) | 1-1.5 | 2-3 | 3-5 | 4-6 | 8-10 | 10-15 |
